  1. Design parameters (and specifications) of the TRIFECTA Cadillac ATS LTG MY2013/MY2014+ T30.1 intake powerkit and corresponding ECM software reprogramming: -Gains of +59 ft-lbs and +52 WHP under the curve (on 87 octane) (Peak gains of +55 ft-lbs and +33 WHP) -Retains the OE fascia cold air ducting and light weight heat shielding airbox assembly: draws colder air from the OE airbox front port and not the hot air of the engine bay -Seamless CNC mandrel formed construction -Retains all OE connector positions and connectors: retains the OE PCV system; maintains emissions readiness -Replaces the restrictive and turbulent sound baffle with a direct and smooth air path -321 stainless steel for temperature stability, strength of the material, and heat rejection vs aluminum intake pipes: keeps the intake temperatures cooler -Ceramic coated for additional engine bay heat rejection -Improves both power and turbo spool speed -C.A.R.B. pending -Made in the USA Specifications of the corresponding TRIFECTA ECM software reprogramming for the TRIFECTA T30.1 Cadillac ATS 2.0T LTG MY2013/MY2014+ LTG intake powerkit: -Powertrain calibration has been tested and validated for various environments, such as cold/heat, elevation, and variations in fuel quality -Extended testing of 100,000 miles with 100 hrs of wide open throttle testing -Power feels linear and immediately responsive -Retains all GM OE diagnostics and ECM functionality -Retains all OE error code reporting and functionality -Emissions readiness checks are present; maintains emissions readiness -Maintains functionality of ABS and TC systems -Knock detection mechanisms and OE engine knock detection sensitivity is retained -Return to stock functionality included with flash loader Installation Notes: -Estimated installation time of ~20 minutes -Implements additional clearance for all of OE plastic protrusions on the OE radiator fan: does not interfere with the fan shroud -Includes all required hardware for installation -Premium fuel is recommended, but not required Dyno sheet: TRIFECTA T30.1 Cadillac ATS LTG Intake Powerkit dyno graph (87 octane pump gas) (this vehicle is a 2013 Cadillac ATS with a LTG 2.0T engine) - stock wheels/tires: Additional information and availability: -Please contact TRIFECTA Performance: info@trifectaperformance.com or Contact Us for more information -The TRIFECTA T30.1 air intake powerkit and corresponding powertrain calibration is available exclusively through TRIFECTA Performance and WOT-tuning; (as of September 9th 2014): wholesale inquiries are welcome though provided that you are an existing and active TRIFECTA reseller. -This air intake powerkit includes a TRIFECTA powertrain calibration file specific to your vehicle and includes a flash loader device -Powertrain calibrations currently exist for the US, EU, RUS/CIS, MEC, and Asia areas, with more regions to follow -Pricing TBA
  2. Release Notes: - (TRIFECTA) Improved Power Delivery between 4000 to 5500 RPM. - (TRIFECTA) Low end torque improved by 20 ft-lbs @ 2500 RPM. - (TRIFECTA) Octane adaptive featureset revision increment. - (TRIFECTA) Improved fuel economy under hill climb conditions. - (TRIFECTA) GM Base Calibration updated to September 6th 2014 release. - (GM) Improved closed loop transition state logic. - (GM) Improved MAF polling rate. - (GM) Fixed CE adaptivity issue with updating MyLink failing. - (GM) Fixed ECM ring 60 saturation on CAN BUS resulting in prolonged delay issue in BCM null state triggers.
  3. Design parameters (and specifications) of the TRIFECTA Cadillac ATS 3.6 MY2013/MY2014+ LFX supercharger powerkit and corresponding ECM software reprogramming: -Gains of +175 ft-lbs and +168 WHP (on 91 octane, Peak gains of +129 ft-lbs and +168 WHP) -Vortech V2 Si / (V2 Ti optional) supercharger head unit (Vortech V7 and V3 TBA) -Supercharger bracket CNC machined from 7075-T6, FEA/CAD designed for optimum critical strength and weight effectiveness -High efficiency bar and plate air to air intercooler -Optimum belt wrap around the supercharger pulley, >190 degrees of belt wrap -Belt routing reuses the OE accessories, retains use of OE harmonic balancer -Does not interfere with Air Conditioning system performance -Retains the OE catalytic converters and maintains emissions readiness -No cutting or splicing of any OE wiring; adapter and extension harnesses are included -Retains the OE PCV system; maintains emissions readiness -Fits under the stock hood -Retains the OE belt tensioner for extended belt lifespan and engine accessory lifespan -Idler pulley design utilizes 76mm idler pulley diameter and severe duty rated ceramic ball bearings for increased belt life and idler pulley longevity -Designed to be silent and reliable: without increased interior NVH during vehicle operation -Includes an aFe Pro Dry S synthetic media high air filer (K&N filter optional) -Utilizes a Turbosmart recirculating bypass valve for accuracy of metered air -Powertrain calibration has been tested and validated for various environments, such as cold/heat and elevation -Extended testing of 100,000 miles with 100 hrs of wide open throttle testing Specifications of the corresponding TRIFECTA ECM software reprogramming for the TRIFECTA supercharged Cadillac ATS 3.6 MY2013/MY2014+ LFX : -Proprietary TRIFECTA 3.5bar operating system maintains accuracy of the metered air and air pressure to 3.5bar -Powertrain calibration has been tested and validated for various environments, such as cold/heat, elevation, and variations in fuel quality -Power feels linear and immediately responsive -Retains all GM OE diagnostics and ECM functionality -Retains all OE error code reporting and functionality -Emissions readiness checks are present; maintains emissions readiness -Maintains functionality of ABS and TC systems -Proprietary TRIFECTA OS maintains OE functionality of the Haldex AWD system, with rebalanced torque biasing -Knock detection mechanisms and OE engine knock detection sensitivity is retained -Cold start performance is flawless and vehicle start is immediate -Return to stock functionality included with flash loader Specifications of the TRIFECTA Performance MY2013/MY2014+ Cadillac ATS 3.6 Hydra-Matic 6L45 6-Speed automatic transmission TCM calibration software reprogramming: -Supplementary 6L45 transmission TCM reprogramming compliments the ECM reprogramming and completes the TRIFECTA Powertrain Calibration: designed to work in unison with the ECM reprogramming for optimized performance -Improved shift times in adverse shift patterns -Improved shift logic -Does not shorten transmission life or increase cooling requirements -Retains all OE diagnostics and TCM functionality -Retains all OE error code reporting and functionality -Improved fuel economy with improvements made to torque converter slip profiles Installation Notes: -Estimated installation time of ~6 hours -Requires front bumper removal (intercooler installation) -Does not require lift for installation -No cutting, splicing, or soldering of OE wiring; adapter harnesses are included: OE plugs -Premium fuel is recommended, but not required Dyno sheet: TRIFECTA T50 Supercharger Powerkit LFX dyno graph (91 octane pump gas) (this vehicle is a 2014 Cadillac ATS Premium with a LFX 3.6 engine) - stock wheels/tires: Additional information and availability: -Please contact TRIFECTA Performance: info@trifectaperformance.com or visit WOT-tuning: www.trifectaperformance.com for more information -This supercharger powerkit and corresponding powertrain calibration is available exclusively through TRIFECTA Performance and WOT-tuning; (as of June 20th 2014): wholesale inquiries are welcome though provided that you are an existing and active TRIFECTA reseller -This supercharger powerkit includes a TRIFECTA powertrain calibration file specific to your vehicle and includes a flash loader device -Powertrain calibrations currently exist for North American vehicles only, with more regions to follow -Pricing TBA
  4. Design parameters (and specifications) of the Cadillac CTS 2.0T LTG Forged Connecting Rods: -Produced from vacuum degassed 4340 chromoly alloy steel. -FEA/CAM/CAD designed with a fully machined profile removes excess weight from noncritical areas while retaining maximum material in strength critical areas for the lightest and strongest LTG connecting rods. -Specific TRIFECTA design specifications creates a unique profile that minimizes localized stress concentrations by utilizing increased minimum thickness on cap cross sections and bolt stress sections. Utilizes an elongated ribbed center mass for improved stress distribution while reducing windage. -Tapered pin end reduces reciprocating mass and maintains compatibility vs the OE LTG pistons. -Features bronze wrist pin bushings precision finished to less than 4 RA on the wrist pin bore. -Multiphase heat treated, stress relieved, and then full coverage shot peened after CNC machining for improved fatigue strength. -Each connecting rod is individually magnafluxed to be without void or flaw. -Each connecting rod is weight matched to +- 0.5 grams. -Features OE GM LTG connecting rod length, PE/BE width, and PE/BE bore size for compatibility with both the stock engine pistons and TRIFECTA specification LTG forged pistons (Stress relieved 2618-T61 forged aluminum, available separately) -Features proprietary ARP 7/16 Custom Age 625+ cap screws utilizing 100% thread engagement. -Retains compatibility with both TRIFECTA's high performance engine recalibration and the stock engine calibration -When purchased together with matching TRIFECTA LTG Forged Pistons, Piston and Rod combination will weigh within 1 gram of stock pistons (optional featureset); does not require rotating assembly rebalancing -Extended testing of 100,000 miles with over 100 hrs of wide open throttle testing -Designed and Made in the USA Additional information and availability: -Please contact TRIFECTA: info@trifectaperformance.com or Contact Us for more information. -TRIFECTA Specification LTG forged connecting rods are available exclusively through TRIFECTA and WOT-tuning; the TRIFECTA Specification is specific and proprietary to the TRIFECTA Group, there are no 3rd parties authorized at present to resell TRIFECTA Specification Components (as of December 28th 2013): wholesale inquiries are welcome though provided that you are an existing and active TRIFECTA reseller -TRIFECTA Forged Connecting Rods includes a TRIFECTA powertrain recalibration file and flash loader device, installation kit, and is RTR with everything necessary for installation with the exception of additional engine coolant, engine oil, and other fluids -Powertrain calibrations currently exist for the US, EU, MEC, and Asia areas, with more regions to follow -Pricing TBA
  5. Specifications of the TRIFECTA Performance Cadillac CTS 3.6 MY2014 LFX ECM software reprogramming: -Gains of +34 ft-lbs and +27 WHP under the curve (and +19 ft-lbs and +11 WHP peak on 91 octane) -Powertrain calibration has been tested and validated for various environments, such as cold/heat, elevation, and variations in fuel quality -Power feels linear and immediately responsive -Retains all GM OE diagnostics and ECM functionality -Retains all OE error code reporting and functionality -Emissions readiness checks are present; emissions compliant -Maintains functionality of ABS and TC systems -Knock detection mechanisms and OE engine knock detection sensitivity is retained -Return to stock functionality included with flash loader Specifications of the TRIFECTA Performance MY2014+ Cadillac CTS 3.6 (and MY2014+ CTS V-Sport) Aisin 8-Speed automatic transmission TCM calibration software reprogramming: -Supplementary Aisin transmission TCM reprogramming compliments the ECM reprogramming and completes the TRIFECTA Powertrain Calibration: designed to work in unison with the ECM reprogramming for optimized performance -Improved shift times in adverse shift patterns -Improved shift logic -Does not shorten transmission life or increase cooling requirements -Retains all OE diagnostics and TCM functionality -Retains all OE error code reporting and functionality -Improved fuel economy with improvements made to torque converter slip profiles Installation Notes: -Estimated installation time of ~20 minutes -Premium fuel is recommended, but not required Dyno sheet: LFX dyno graph (91 octane pump gas) (this vehicle is a 2014 Cadillac CTS Premium with a LFX 3.6 engine) - stock wheels/tires: Additional information and availability: -This powertrain calibration is available exclusively through TRIFECTA Performance and WOT-tuning; (as of May 20th 2014): wholesale inquiries are welcome though provided that you are an existing and active TRIFECTA reseller -This powertrain calibration includes a TRIFECTA powertrain calibration file specific to your vehicle and includes a flash loader device -Powertrain calibrations currently exist for North American vehicles only, with more regions to follow -Pricing TBA
  6. Specifications of the TRIFECTA Performance Cadillac ATS 3.6 MY2013--MY2015 LFX ECM software reprogramming: -Gains of +29 ft-lbs and +27 WHP under the curve (and +16 ft-lbs and +19 WHP peak) -Powertrain calibration has been tested and validated for various environments, such as cold/heat, elevation, and variations in fuel quality -Power feels linear and immediately responsive -Retains all GM OE diagnostics and ECM functionality -Retains all OE error code reporting and functionality -Emissions readiness checks are present; emissions compliant -Maintains functionality of ABS and TC systems -Knock detection mechanisms and OE engine knock detection sensitivity is retained -Return to stock functionality included with flash loader Specifications of the TRIFECTA Performance MY2013--MY2015 Cadillac ATS 3.6L Hydra-Matic 6L45 6-Speed automatic transmission TCM calibration software reprogramming: -Supplementary 6L45 transmission TCM reprogramming compliments the ECM reprogramming and completes the TRIFECTA Powertrain Calibration: designed to work in unison with the ECM reprogramming for optimized performance -Improved shift times in adverse shift patterns -Improved shift logic -Does not shorten transmission life or increase cooling requirements -Retains all OE diagnostics and TCM functionality -Retains all OE error code reporting and functionality -Improved fuel economy with improvements made to torque converter slip profiles Installation Notes: -Estimated installation time of ~20 minutes -Premium fuel is recommended, but not required Additional information and availability: -This powertrain calibration includes a TRIFECTA powertrain calibration file specific to your vehicle and includes TRIFECTA Flash Loader (EZ Flash Cable) -Powertrain calibrations currently exist for North American vehicles only, with more regions to follow
  7. Additional information and availability: -Please contact TRIFECTA Performance: info@trifectaperformance.com or Contact Us for more information -This powertrain calibration will be available exclusively through TRIFECTA Performance and WOT-tuning; (as of May 5th 2014): wholesale inquiries are welcome though provided that you are an existing and active TRIFECTA reseller -This powertrain calibration includes a TRIFECTA powertrain calibration file specific to your vehicle and includes a flash loader device -Pricing TBA
  8. TRIFECTA Performance

    J-body Concept Cars

    '01 TurboSport '02 TurboSport '01 Super Sport
  9. TRIFECTA's LF3 ECM calibration is complimented by a fully developed 8-speed Aisin transmission calibration to support the increased power delivery profile. The complete powertrain calibration also includes ESC (Stabilitrak) and eLSD (electronic Limited-Slip Differential) program enhancements. TRIFECTA's powertrain calibrations are tested and validated for various environments, such as cold/heat, elevation, and variations in fuel quality. Each vehicle type is validated on TRIFECTA's test fleet for a minimum of 100,000 miles and 100 hours of full throttle application prior to retail release. We make no compromises in comprehensiveness, safety, and power. Specifications of the TRIFECTA Performance Cadillac CTS V-Sport 3.6TT MY2014 LF3 ECM software reprogramming: -Retains all GM OE diagnostics and ECM functionality -Retains all OE error code reporting and functionality -Emissions readiness checks are present; emissions compliant -Maintains functionality of ABS and TC systems -Knock detection mechanisms and OE engine knock detection sensitivity is retained -Return to stock functionality included with flash loader Specifications of the TRIFECTA Performance Cadillac CTS V-Sport 3.6TT MY2014 Aisin 8-Speed automatic transmission TCM calibration software reprogramming: -Improved shift times in adverse shift patterns -Improved shift logic -Does not shorten transmission life or increase cooling requirements -Retains all OE diagnostics and TCM functionality -Retains all OE error code reporting and functionality Purchase details: -This powertrain calibration includes a Trifecta powertrain calibration file specific to your vehicle and includes a flash loader device -Powertrain calibrations currently exist for North American vehicles only, with more regions to follow
  10. Design parameters (and specifications) of the Cadillac CTS 2.0T LTG Forged Pistons: -Stock piston dome and engine compression -Compatible with both the stock engine connecting rods and 4340 Forged Connecting Rods (Available separately) -Stress relieved 2618-T61 forged aluminum construction -Retains compatibility with both the high performance engine calibration and the stock engine calibration -Lightweight piston design -Improved piston rings and ringland design, with tool steel top rings, napier 2nd ring and improved oil control rings; hard anodized top ringland -Progressive staggered anti-detonation grooves (on top ringland) -Tapered piston skirt design to reduce piston rock -Low friction Zylan skirt coating for extended service life -Tool Steel wrist pins -When purchased together with matching 4340 Forged Connecting Rods, Piston and Rod combination will weigh within 1 gram of stock pistons (optional featureset); does not require rotating assembly rebalancing -Optional dry phosphate exterior finish -Pregapped piston rings for ease of assembly -Extended testing of 100,000 miles with over 100 hrs of wide open throttle testing -Made in the USA Additional information and availability: -Please contact Trifecta Performance: info@trifectaperformance.com or visit WOT-tuning: www.trifectaperformance.com for more information -Trifecta Specification Forged Pistons are available exclusively through Trifecta Performance and WOT-tuning; the Trifecta Specification is specific and proprietary to the Trifecta Performance Group, there are no 3rd parties authorized at present to resell Trifecta Specification Components (as of December 28th 2013): wholesale inquiries are welcome though provided that you are an existing and active Trifecta reseller -Trifecta Forged Pistons includes a Trifecta powertrain calibration file and flash loader device, installation kit, and is RTR with everything necessary for installation with the exception of additional engine coolant, engine oil, and other fluids -Powertrain calibrations currently exist for the US, EU, MEC, and Asia areas, with more regions to follow -Pricing TBA
